600 LB Butt Welded Swing Check Valve,WCB Body,16 Inch



Model:H64Y-600LB-DN400-WCB

STV Valve Technology Group Co., Ltd is a professional leader China Swing Check Valve,BS 1868 Swing Check Valve,API 6D Swing Check Valve,16 IN Swing Check Valve,Class 600 Swing Check Valve ,Butt Welded Swing Check Valve,API Swing Check Valve manufacturer with high quality and competitive price.

To learn more about these valve Welcome to contact our sales@stvvalve.com
Date Sheet:600 LB Butt Welded Swing Check Valve,WCB Body,16 Inch

<form class="cart" action="https://stvvalves.com/product/600-lb-butt-welded-swing-check-valve-wcb-body-16-inch/" enctype="multipart/form-data" method="post">


<button class="button alt addquotelistbutton_prodpage product_type_simple" type="button" data-product_id="5125" data-product_sku="" data-quantity="1">Add to Quote</button></span>



</form>
Categories: Cast Steel Check Valve, CHECK VALVE Tags: 16 IN Swing Check Valve, API 6D Swing Check Valve, API Swing Check Valve, BS 1868 Swing Check Valve, Butt Welded Swing Check Valve, Class 600 Swing Check Valve, Swing Check Valve
  • Description

Description

Design and Manufacture： BS 1868,ASME B16.34,API 6D

Inspection and Test：API598,API600 or API 6D

End Flange Dimension：ASME B16.5(for NPS≤24,ASME B 16.47 series B,API 605,ASME B16.47 A Series,MSS SP-44(for NPS＞24)

BW end Dimension：ASME B16.25

Face to Face and End to End：ASME B16.10

Pressure-temperature ratings：ASME B16.34

Wall Thickness Dimension：API 600,BS 1868

Product Range

Body material: carbon steel, stainless steel, alloy steel,bronze

Nominal diameter:1/2″~48″(DN15~DN1200)

End Connection: RF,RTJ, BW

Pressure range: Class150~2500(PN16~PN420)

Working temperature:-196℃~+560℃
